Y2 Series 3 Phase AC Induction Motors (ABB Models)
3 Phase AC Induction Motors
Y2 Series 3 Phase AC Induction Motors
1 2 3

Y2 Series 3 Phase AC Induction Motors (ABB Models)

  • Power: 0.06 kW~22 kW
  • Poles: 2P, 4P, 6P
  • Frequency: 50Hz/60Hz
  • Protection Class: IP54, IP55, IP56
  • Insulation Class: F
  • Bearing: C&U, NSK, SKF
Share With :

AOKMAN® Y2 series 3 phase AC asynchronous motors (induction motors) adopts IEC standards, ABB Motor square design, cast aluminum housing, detachable mounting feet. Dustproof and waterproof, low noise, low vibration, energy saving, long service life.

Components:

1. Housing: Die-casting Aluminum
2. Shaft: 40Cr
3. Magnet Wires: QZ-2/155, QZY-2/180
4. Stator & Rotor Core: Silicon Steel Sheets DW470, DW600
5. Bearings: C&U, NSK, SKF

Models & Parameters:

  • Voltage: 380VAC
  • Frequency: 50Hz/60Hz
  • Power: 0.06 kW~22 kW (0.08HP~30HP)
  • Poles: 2P, 4P, 6P
  • Output Speed: 3000RPM, 1500RPM, 1000RPM
  • Frame Sizes: H56~H180
  • Shaft Diameter: Φ9~Φ48
  • Ingress Protection: IP54, IP55, IP56
  • Insulation Level: F
  • Duty: Continuous duty (S1)
  • Cooling: IC411

Mounting Options:

  • IM B3
  • IM B5, IM B14
  • IM B34, IM B35
